Scientific Backgroup
Optical Therapeutic Window
Scientific research shows that sunlight affects human cells in ways similar to its effects on plant cells.
- The therapeutic optical window for humans is 600–1300 nm.
- The safe wavelength range is approximately 600–900 nm, which can penetrate skin up to a depth of 4 cm.
Cellular Mechanisms
When light is absorbed, it stimulates mitochondria in human cells to release:
- Adenosine Triphosphate (ATP) – the main energy currency of cells, powering muscle movement, nerve signals, and other biological processes.
- Reactive Oxygen Species (ROS) – highly reactive oxygen containing molecules essential for cell signaling and immune response (but harmful in excess).
- Nitric Oxide (NO) – a gaseous signaling molecule that relaxes blood vessels (vasodilation), lowering blood pressure and increasing blood flow, oxygen, and nutrient delivery.
Adequate red light therapy promotes better cell proliferation, motility, and reproduction.
Dose Response (The Arndt Schulz Curve)
Light therapy follows a biphasic dose response:
- Too little light → minimal effect.
- Too much light → inhibition or negative effects.
The goal is to find the “sweet spot” within the therapeutic window.
Key Variables
- Wavelength – Determines penetration depth.
- Blue light → skin surface.
- Red light (600–700 nm) → 0.5–2 cm depth.
- Near infrared (NIR, 760–930 nm) → 3–4 cm depth.
- The safe wavelength range is approximately 600–900 nm, which can penetrate skin up to a depth of 4 cm.
- Irradiance (Power Density) – Measured in mW/cm² (or W/m²; 1 mW/cm² = 10 W/m²). The typical therapeutic window is 10–50 mW/cm².
- Energy Density (Fluence) – Measured in J/cm².
Formula: Session time (seconds) = [Target Dose (J/cm²) × 1000] / Power Density (mW/cm²) - Penetration & Skin Tone – Dark colored skin absorbs more red and NIR light, generating more heat and reducing therapeutic effect. Use lower intensity and longer session times.
Important: Wavelengths above 1000 nm resonate with water molecules and produce excess heat, making them less safe for general photobiomodulation.
Device Specifications
Model KT8301 - General Purpose (All-in-One)
LED configuration: 5 wick LED device with Red + Near Infrared.
Applications: Facial rejuvenation, muscle recovery, joint pain, general skin health
| Parameter | Red Light (590–740 nm) | Near Infrared (760–930 nm) | Combined (both lights) |
|---|---|---|---|
| Irradiance (Power Density) | 3 peaks, total 10 mW/cm² | 2 peaks, total 20 mW/cm² | 30 mW/cm² total |
| Penetration depth | 0–2.5 cm | ~3–4 cm | 0–4 cm |
| Energy Density (Fluence) | 4–15 J/cm² | 10–40 J/cm² * | 10–40 J/cm² |
| Standard session time | 10–20 min | 10–15 min per area | 10–20 min |
*Note: Doses above 40 J/cm² may enter the inhibitory range for some indications.
Start with lower doses and increase gradually.*
Model KT8302 / KT8303 - Face Mask & Head Piece
LED bulbs: Blue + Red + Near Infrared
Applications: Anti bacterial, facial rejuvenation, acne, hair growth, superficial wound healing, skin pain relief, muscle recovery, general skin health
| Parameter | Blue Light (400–450 nm) | Red Light (580–750 nm) | Near Infrared (810–850 nm) |
|---|---|---|---|
| Irradiance (Power Density) | 1 peak, 5 mW/cm² | 3 peaks, 30 mW/cm² | 1 peak, 20 mW/cm² |
| Penetration depth | ~0 cm (surface) | 0–2 cm | ~3–4 cm |
| Energy Density (Fluence) | 4–5 J/cm² | 4–5 J/cm² * | 6–8 J/cm² |
| Standard session time | 15–20 min | 15–20 min per area | 15–20 min |
Recommendation: Using both red and NIR lights together provides the broadest therapeutic effect.
Safety Instructions
- Thermal safety: The device must be kept away from direct skin contact to avoid low heat injury. The temperature in the vicinity should remain below 45°C (113°F).
- Skin contact parts: The inner side shall have a removable silicone mesh. The silicone material resists bacteria, is easy to wipe dry, and simple to clean.
- Skin irritation: The device should cause no skin irritation.
- Electrical safety: All electrical components must meet UL specifications.
Important Disclaimer – Photobiomodulation Device
Disclaimer: This device is not intended to diagnose, treat, cure, or prevent any disease. The statements regarding light therapy parameters are based on published scientific literature and are provided as general guidance. Individual results may vary. Consult a healthcare professional before starting any new therapy, especially if you have a medical condition or are pregnant.
